TMR500-DLs Lifting AGV

The TMR500-DLs is a back-lifting AGV that uses laser SLAM navigation technology. The vehicle can rotate in place while the cargo remains stationary relative to the ground. This model is compact and agile, offering high speed, and is suitable for small to medium-sized, multi-category warehouse picking operations. It is ideal for warehouses of up to tens of thousands of square meters and is widely applicable across industries such as e-commerce, retail, pharmaceuticals, food, daily necessities, manufacturing, and automotive production.

Contact Us
Product Features

SLAM Navigation: No need for reflective panels or magnetic strips, easy deployment, and millimeter-level positioning.
Compact and Flexible: 360-degree rotation, stable lifting and handling, automatic obstacle avoidance, and adaptability to changing environments.
Flexible Intelligent Scheduling: Intelligent path planning and control algorithms for optimized operations.

Technical Parameters

Dimensions	L 906 x W 697 x H 320 mm
Weight	150Kg
Drive	Dual-wheel differential drive
Rated Load Capacity	500 Kg
Navigation Method	Laser navigation
Navigation Accuracy	±10cm
Maximum Speed	1.2 m/s
Maximum Lifting Height	40 mm
Repeatability Accuracy	±5cm
Operating Temperature Range	-5℃ ~ 50℃
CAN	CAN Open
Wireless Connection	802.11 b/g/n/ac
Safety Protection	Safety laser
Manual	Emergency Stop Button
Protection Level	IP54
