System composition
Preheating plates, centrifugal pumps, vacuum pumps, heaters, evaporation chambers, shell-and-tube condensers, raw material tanks, finished product tanks and racks as well as connecting pipes.


System composition
Preheating plates, centrifugal pumps, vacuum pumps, heaters, evaporation chambers, shell-and-tube condensers, raw material tanks, finished product tanks and racks as well as connecting pipes.


|
Rated evaporation capacity |
50L/h |
|
Installed power |
6.05KW |
|
Feed temperature |
Normal temperature, discharge temperature ﹤48℃ |
|
Steam consumption |
22KG/h, steam inlet pressure: not less than 7bar |
|
Cooling water consumption |
1000Kg/h 25℃ in, 39℃ out |
|
Water pressure |
Not less than 2bar |
|
First effect evaporation temperature |
75℃ |
|
Second effect evaporation temperature |
62℃ |
|
Three-effect evaporation temperature |
48℃ |
